Mô tả thiết bị mạng Cisco 100BASE-FX SFP

The Cisco^® 100BASE-X Small Form-Factor Pluggable (SFP) device (Figure 1) is a hot-swappable input/output device that plugs into Fast Ethernet ports, dual-rate Fast/Gigabit Ethernet ports, or Gigabit Ethernet ports of a Cisco switch or router, linking the port with the fiber cabling network.

Main features include the following:

●   Hot-swappable when deployed, the switch or router does not have to reboot

●   Supports the “pay-as-you-populate” model

●   Interchangeable with other 100BASE-X SFPs on the same line card

●   Supports the Cisco quality ID feature that enables the switch or router to identify whether or not the SFP is a Cisco qualified SFP

●   Optically interoperable with respective 100BASE-X Ethernet interfaces on the same link

Cisco 100BASE-FX SFP

The Cisco 100BASE-FX SFP operates on ordinary multimode fiber-optic (MMF) link spans up to 2 kilometers (km) long.

GLC-FE-100FX modules operate in Fast Ethernet or dual-rate Fast/Gigabit Ethernet ports of Cisco switches and routers.

GLC-FE-100FX-RGD modules operate in Fast Ethernet or dual-rate Fast/Gigabit Ethernet ports of Cisco Industrial Ethernet and SmartGrid switches and routers.

GLC-GE-100FX modules operate in Gigabit Ethernet ports of Cisco switches and routers.

All these modules are interoperable with industrywide interfaces compliant to the IEEE 100BASE-FX standard.

Cisco 100BASE-LX10 SFP

The Cisco 100BASE-LX10 SFP operates on ordinary single-mode fiber-optic (SMF) link spans up to 10 km long.

GLC-FE-100LX modules operate in Fast Ethernet or dual-rate Fast/Gigabit Ethernet ports of Cisco switches and routers.

GLC-FE-100LX-RGD modules operate in Fast Ethernet or dual-rate Fast/Gigabit Ethernet ports of Cisco Industrial Ethernet and SmartGrid switches and routers.

These modules are interoperable with industrywide interfaces compliant to the IEEE 100BASE-LX10 standard.

Cisco 100BASE-BX10 SFP

The Cisco 100BASE-BX10 (part numbers GLC-FE-100BX-D and GLC-FE-100BX-U) SFPs operate on ordinary SMF single-strand link spans up to 10 km long. A 100BASE-BX10-D device is always connected a 100BASE-BX10-U device with a single strand of standard SMF with an operating transmission range up to 10 km. The communication over a single strand of fiber is achieved by separating the transmission wavelength of the two devices as depicted in Figure 2. 100BASE-BX10-D transmits a 1550-nm channel and receives a 1310-nm signal, whereas a 100BASE-BX10-U transmits a 1310-nm wavelength and receives a 1550-nm signal. Note in Figure 2 the presence of a wavelength-division multiplexing (WDM) splitter integrated into the SFP to split the 1310-nm and 1550-nm light paths.

Cisco 100BASE-EX SFP

The Cisco 100BASE-EX SFP operates on ordinary SMF link spans up to 40 km long.

GLC-FE-100EX modules operate in Fast Ethernet or dual-rate Fast/Gigabit Ethernet ports of Cisco switches and routers.

Cisco 100BASE-ZX SFP

The Cisco 100BASE-ZX SFP operates on ordinary SMF link spans up to 80 km long.

GLC-FE-100ZX modules operate in Fast Ethernet or dual-rate Fast/Gigabit Ethernet ports of Cisco switches and routers.

Cisco 100BASE-T Copper SFP

The 100BASE-T SFP operates on standard Category 5 unshielded twisted-pair copper cabling of link lengths up to 100 m (328 ft). It supports Industrial temperature range of -40 to 85C.

Platform Support

The Cisco SFPs are supported across a variety of Cisco switches, routers, and optical transport devices. For more details, refer to the document Cisco 100M Ethernet SFP Compatibility Matrix.

Connectors and Cabling

Connectors: Dual LC connector (GLC-FE-100FX, GLC-FE-100FX-RGD, GLC-GE-100FX, GLC-FE-100LX, GLC‑FE-100LX-RGD, GLC-FE-100EX, and GLC-FE-100ZX) or single LC connector (GLC-FE-100BX-D and GLC‑FE-100BX-U)

Table 1 provides cabling specifications for the SFPs for installation in a Fast Ethernet SFP port. Note that all SFP ports have LC-type connectors, and the minimum cable distance for all SFPs listed (MMF and SMF [G.652]) is 2 meters (6.5 feet).

Table 1.       SFP Port Cabling Specifications

Dimensions

Dimensions (H x W x D): 8.5 x 13.4 x 56.5 mm

Environmental Conditions and Power Requirements

●   Operating temperature range:

◦     Commercial temperature range (COM): 0 to 70°C (32 to 158°F), applicable to GLC-FE-100FX, GLC‑FE-100LX, GLC-GE-100FX, GLC-FE-100BX-D, GLC-FE-100BX-U, GLC-FE-100EX, and GLC‑FE‑100ZX

◦     Industrial temperature range (IND): -40 to 85°C (-40 to 185°F), applicable to GLC-FE-100FX-RGD, GLC-FE-100LX-RGD and GLC-FE-T-I

●   Storage temperature range: -40 to 85°C (-40 to 185°F)

●   Power consumption:

◦     GLC-FE-100FX, GLC-FE-100FX-RGD, GLC-FE-100BX-D, GLC-FE-100BX-U, GLC-FE-100EX, and GLC-FE-100ZX modules consume up to 1W per port

◦     GLC-GE-100FX modules typically consume 1.5W per port (up to 1.7W)

◦     GLC-FE-T-I modules typically consume 1W per port
